Description
Life Time Warranty By Kingston Malaysia
What’s in the box:-
1x Kingston RAM DIMM DDR4 Non-ECC Memory
DESCRIPTION:-
This document describes ValueRAM’s KVR26N19S6/4 as a 512M
x 64-bit (8GB) DDR4-2666 CL19 SDRAM (Synchronous DRAM),
1Rx16, memory module, based on four 512M x 16-bit FBGA
components. The SPD is programmed to JEDEC standard
latency DDR4-2666 timing of 19-19-19 at 1.2V. Each 288-pin
DIMM uses gold contact fingers. The electrical and mechanical
specifications are as follows:
FEATURES:-
• Power Supply: VDD = 1.2V Typical
• VDDQ = 1.2V Typical
• VPP = 2.5V Typical
• VDDSPD = 2.2V to 3.6V
• Nominal and dynamic on-die termination (ODT) for
data, strobe, and mask signals
• Low-power auto self-refresh (LPASR)
• Data bus inversion (DBI) for data bus
• On-die VREFDQ generation and calibration
• Single-rank
• On-board I2 serial presence-detect (SPD) EEPROM
• 8 internal banks; 2 groups of 4 banks each
• Fixed burst chop (BC) of 4 and burst length (BL) of 8
via the mode register set (MRS)
• Selectable BC4 or BL8 on-the-fly (OTF)
• Fly-by topology
• Terminated control command and address bus
• PCB: Height 1.23” (31.25mm)
• RoHS Compliant and Halogen-Free
SPECIFICATIONS :-
CL(IDD) : 19 cycles
Row Cycle Time (tRCmin) : 45.75ns(min.)
Refresh to Active/Refresh
Command Time (tRFCmin) : 350ns(min.)
Row Active Time (tRASmin) : 32ns(min.)
Maximum Operating Power : TBD W*
UL Rating : 94 V – 0
Operating Temperature : 0o C to +85o C
Storage Temperature : -55o C to +100o C
*Power will vary depending on the SDRAM used
